• WLAN Interface |
Standards |
IEEE 802.11i for Wireless Security
IEEE 802.3u for 10/100BaseT(X)
IEEE 802.3af for Power-over-Ethernet |
Security |
WPA /WPA2-Personal and Enterprise (IEEE 802.1X/RADIUS, TKIP, and AES) |
• Interface |
LAN Port |
10/100BaseT(X), auto negotiation speed (RJ45-type) |
Console |
RS-232 (RJ45-type) |
LED Indicators |
PWR1, PWR2, PoE, FAULT, STATE, 10M, 100M |
Alarm Contact |
1 relay output with current carrying capacity of 1 A @ 24 VDC |
Digital Inputs |
2 electrically isolated inputs
• +13 to +30 V for state “1”
• +3 to -30 V for state “0”
• Max. input current: 8 mA |
• Physical Characteristics |
Housing |
Metal, providing IP30 protection |
Weight |
700 g |
Dimensions |
52.85 x 135 x 105 mm (2.08 x 5.31 x 4.13 in) |
Installation |
DIN-Rail mounting, wall mounting |
• Environmental Limits |
Operating Temperature |
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
Storage Temperature |
-40 to 85°C (-40 to 185°F) |
Ambient Relative Humidity |
5 to 95% (non-condensing) |
• Power Requirements |
Input Voltage |
12 to 48 VDC, redundant dual DC power inputs or 48 VDC Power-over-Ethernet (IEEE 802.3af compliant) |
Note |
*Compliant with EN 50155 on 24 VDC |
Connector |
10-pin removable terminal block |
Power Consumption |
12-48 VDC, 0.121-0.494 A (max.)
Maximum 5.6 watts |
Reverse Polarity Protection |
Present |
• Standards and Certifications |
Safety |
UL 60950-1, EN 60950-1 |
EMC |
FCC Part 15 Subpart B Class A, EN 55022/55024 |
Rail Traffic |
EN 50155*, EN 50121-1/4 |
Note |
*Complies with a portion of EN 50155 specifications. Please contact Moxa or a Moxa distributor for details. |
• Reliability |
MTBF (mean time between failures) |
485,432 hrs |
