WLAN Standards |
- 2.4 GHz: 802.11ax with 1024 QAM support, 20/40 MHz
5 GHz: 802.11ax with 1024 QAM support,
20/40/80 MHz
|
Frequency Band for US (20 MHz operating channels) |
- 5.745 to 5.825 GHz (5 channels)
2.412 to 2.462 GHz (11 channels) 5.180 to 5.240 GHz (4
channels) 5.500 to 5.700 GHz (11 channels) DFS (Dynamic Frequency
Selection) channel support: In AP mode, when a radar signal is detected, the device will
automatically switch to another channel. However, according to regulations, after
switching channels, a 60-second availability check period is required before starting
the service. 5.260 to 5.240 GHz (4 channels) DFS (Dynamic Frequency Selection) channel support: In AP
mode, when a radar signal is detected, the device will automatically switch to another
channel. However, according to regulations, after switching channels, a 60-second
availability check period is required before starting the service.
|
Wireless Security |
- WEP encryption (64-bit and 128-bit)
WPA/WPA2/WPA3-Enterprise (IEEE 802.1X/RADIUS, TKIP,
AES) WPA/WPA2/WPA3-Personal
|
Transmission Rate |
- 2.4 GHz:
Up to 573.5 Mbps
5 GHz: Up to 1,201 Mbps
|
Transmitter Power for 802.11a (Dual Chain) |
- 18±1.5 dBm @ 6 Mbps
18±1.5 dBm @ 54 Mbps
|
Transmitter Power for 802.11n (5 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS7 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS7 40 MHz
|
Transmitter Power for 802.11ac (Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS8 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS9 40 MHz 18±1.5 dBm @ MCS0 80 MHz 18±1.5 dBm @ MCS9 80 MHz
|
Transmitter Power for 802.11ax (Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
17±1.5 dBm @ MCS11 20 MHz 18±1.5 dBm @ MCS0 40 MHz 17±1,5
dBm @ MCS11 40 MHz 18±1.5 dBm @ MCS0 80 MHz 17±1.5 dBm @ MCS11 80 MHz
|
Transmitter Power for 802.11b (Dual Chain) |
- 18±1.5 dBm @ 1 Mbps
18±1.5 dBm @ 11 Mbps
|
Transmitter Power for 802.11g (Dual Chain) |
- 18±1.5 dBm @ 6 Mbps
18±1.5 dBm @ 54 Mbps
|
Transmitter Power for 802.11n (2.4 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS7 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS7 40 MHz
|
Transmitter Power for 802.11ac (2.4 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS8 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS7 40 MHz
|
Transmitter Power for 802.11ax (2.4 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS11 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS11 40 MHz
|
Receiver Sensitivity for 802.11a (measured at 5.680 GHz) |
- Typ. -88 @ 6 Mbps
Typ. -72 @ 54 Mbps
|
Receiver Sensitivity for 802.11n (5 GHz; measured at 5.680 GHz) |
- Typ. -88 dBm @ MCS0 20 MHz
Typ. -68 dBm @ MCS7 20 MHz Typ. -84 dBm @ MCS0 40 MHz
Typ. -66 dBm @ MCS7 40 MHz
|
Receiver Sensitivity for 802.11ac (5 GHz) |
- Typ. -88 dBm @ MCS0 20 MHz
Typ. -65 dBm @ MCS8 20 MHz Typ. -85 dBm @ MCS0 40 MHz
Typ. -60 dBm @ MCS9 40 MHz Typ. -81 dBm @ MCS0 80 MHz Typ. -55 dBm @ MCS9 80 MHz
|
Receiver Sensitivity for 802.11ax (5 GHz) |
- Typ. -88 dBm @ MCS0 20 MHz
Typ. -59 dBm @ MCS11 20 MHz Typ. -85 dBm @ MCS0 40 MHz
Typ. -56 dBm @ MCS11 40 MHz Typ. -81 dBm @ MCS0 80 MHz Typ. -52 dBm @ MCS11 80 MHz
|
Receiver Sensitivity for 802.11b (measured at 2.437 GHz) |
- Typ. -96 dBm @ 1 Mbps
Typ. -88 dBm @ 11 Mbps
|
Receiver Sensitivity for 802.11g (measured at 2.437 GHz) |
- Typ. -90 dBm @ 6 Mbps
Typ. -74 dBm @ 54 Mbps
|
Receiver Sensitivity for 802.11n (2.4 GHz; measured at 2.437 GHz) |
- Typ. -90 dBm @ MCS0 20 MHz
Typ. -70 dBm @ MCS7 20 MHz Typ. -87 dBm @ MCS0 40 MHz
Typ. -69 dBm @ MCS7 40 MHz
|
Receiver Sensitivity for 802.11ac (2.4 GHz) |
- Typ. -90 dBm @ MCS0 20 MHz
Typ. -66 dBm @ MCS6 20 MHz Typ. -87 dBm @ MCS0 40 MHz
Typ. -63 dBm @ MCS9 40 MHz
|
Receiver Sensitivity for 802.11ax (2.4 GHz) |
- Typ. -90 dBm @ MCS0 20 MHz
Typ. -59 dBm @ MCS11 20 MHz Typ. -87 dBm @ MCS0 40 MHz
Typ. -56 dBm @ MCS11 40 MHz
|
WLAN Operation Mode |
- Access point
Master Sniffer
|
Antenna |
- External, 2/2 dBi
Omni-directional
|
