| Communication Interface |
| Wireless Standards |
ZigBee 2007 Pro |
| Transmission Power |
11dBm (FCC Certificated) (Max 19dBm) |
| 2.4 GHz Antenna |
5 dBi Omni directional |
| Transmission Range (LoS) |
700 m (Typical) |
| Certification |
Yes |
| Max. Slaves in ZigBee Network |
255 |
| Protocols |
Supports DCON and Modbus RTU Protocols |
| How Swap |
Rotary and DIP switch |
| LED Indicators |
| Power |
1 Red LED, ZigBee Device Power Indicator |
|
| ZigBee Communications |
1 Green LED, ZigBee Communication Indicator |
| Digital Input and Output |
8 Green LEDs for Digital Input
8 Red LEDs for Digital Output |
| Isolation |
| Intra-module Isolated, Field-to-Logic |
2500 VDC |
| EMS Protection |
| ESD (IEC 61000-4-2) |
4 kV Contact for Power Line, Communication Line
and each Channel, 8 kV Air for Random Point |
| EFT (IEC 61000-4-4) |
4 kV for Power |
| Surge |
3 kV for Power Line |
| Power |
| Input Voltage Range |
+10VDC ~ +30 VDC |
| Power Consumption |
2.5 W Max |
| Mechanical |
| Flammability |
Fire Retardant materials (UL94-V0 Level) |
| Dimensions L x W x H) |
96 mm x 33 mm x 110 mm |
| Installation |
DIN-Rail |
| Environment |
| Operating Temperature |
-25°C ~ +75°C (-13°F ~ +167°F) |
| Storage Temperature |
-30°C ~ +80°C (-22°F ~ +176°F) |
| Relativel Humidity |
10 ~ 90% RH, Non-condensing |
