| Digital Input |
| Input Type |
One Common for All Digital Inputs(Sink) |
| On Voltage Level |
+10V ~ 30V |
| Off Voltage Level |
+4V max |
| Input Impedance |
3K Ohms, 0.25W |
| Intra-module Isolation, Field to Logic |
3750Vrms |
| 4KV ESD Protection |
Contact for each channel |
| Digital Output |
| Output Type |
Open-collector(Sink) |
| Max Load Current |
100 mA/ Channel |
| Load Voltage |
5Vdc to 30Vdc |
| Intra-module Isolation, Field to Logic |
3750Vrms |
| 4KV ESD Protection |
Contact for each channel |
| LED Display |
| 1 LED as Power Indicator |
| 16 LEDs as Digital Input & Digital Output Indicators |
| Power |
| Power Consumption |
0.2A @ 5V = 1W ,+/- 5% For Hardware |
| Environment |
| Operating Temperature |
-25 to 75 °C |
| Storage Temperature |
-30 to 85 °C |
| Humidity |
5 to 95% RH, non-condensing |
| Dimensions |
| 30 mm x 102 mm x 115 mm (W x L x H) |
