Model Number |
EX-150AH-US (US model) |
Wi-Fi Modules |
SX-SDMAH-US– Wi-Fi HaLow
SX-SDMAX – Wi-Fi6 |
Wireless LAN |
802.11ah (1x1) external antenna
802.11ax (1x1) internal antenna |
Operating Frequency |
Wi-Fi HaLow: 903Mhz – 927MHz
Wi-Fi 6:
2.4GHz: ch1 – ch11
5GHz (20MHz only):
ch36, 40, 44, 48 (indoor)
ch149, 153, 157, 161, 165 (outdoor) |
Security |
Wi-Fi HaLow:
Open/Enhanced Open
WPA3-Personal
Wi-Fi 6:
Open/Enhanced Open
WPA2-Personal/WPA3-Personal
WPA3/2 Transition mode
Encryption: AES |
Wi-Fi HaLow MCS |
MCS10 (1MHz only)
MCS1 – MCS7 (1/2/4/8MHz) |
Wi-Fi 6 MCS |
MCS0 – MCS11 (up to 144Mbps) |
Ethernet |
RJ-45 x 1
10BASE-T/100BASE-TX |
Operating Environment |
Temperature: -20C to 40C
Humidity: 20% - 90% w/o condensation |
Storage Environment |
Temperature: -20C to 60C
Humidity: 20% - 90% w/o condensation |
Power |
5V +/- 5% (USB Type-C)
12V/24V +/- 5% (DC) |
Power Consumption |
5V: 6.25W
12V/24V: 9.6W |
Dimensions |
100mm x 100mm x 25.5mm (excluding antenna) |
Weight |
150g (including antenna) |
EMC Standards |
FCC Part15 Subpart B Class B
ICES-0003 Class B |
Warranty |
5 years |
Contents |
Body, Antenna
- AC adapter and USB Type-C cable are not included. |
Optional Accessory |
Wall-mount Bracket Type VI |
