WLAN Standards |
- 2.4 GHz: 802.11ax with 1024 QAM support, 20/40 MHz
5 GHz: 802.11ax with 1024 QAM support,
20/40/80 MHz
|
Frequency Band for UN (20 MHz operating channels) |
- 2.412 to 2.472 GHz (13 channels)
5.180 to 5.240 GHz (4 channels) 5.745 to 5.825 GHz (5
channels) Available channels change depending on the selected country or region code.
5.500 to 5.700 GHz (11 channels) DFS (Dynamic Frequency
Selection) channel support: In AP mode, when a radar signal is detected, the device will
automatically switch to another channel. However, according to regulations, after
switching channels, a 60-second availability check period is required before starting
the service. 5.260 to 5.320 GHz (4 channels) DFS (Dynamic Frequency Selection) channel support: In AP
mode, when a radar signal is detected, the device will automatically switch to another
channel. However, according to regulations, after switching channels, a 60-second
availability check period is required before starting the service.
|
Wireless Security |
- WEP encryption (64-bit and 128-bit)
WPA/WPA2/WPA3-Enterprise (IEEE 802.1X/RADIUS, TKIP,
AES) WPA/WPA2/WPA3-Personal
|
Transmission Rate |
- 2.4 GHz:
Up to 573.5 Mbps
5 GHz: Up to 1,201 Mbps
|
Transmitter Power for 802.11a (Dual Chain) |
- 18±1.5 dBm @ 6 Mbps
18±1.5 dBm @ 54 Mbps
|
Transmitter Power for 802.11n (5 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS7 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS7 40 MHz
|
Transmitter Power for 802.11ac (Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS8 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS9 40 MHz 18±1.5 dBm @ MCS0 80 MHz 18±1.5 dBm @ MCS9 80 MHz
|
Transmitter Power for 802.11ax (Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
17±1.5 dBm @ MCS11 20 MHz 18±1.5 dBm @ MCS0 40 MHz 17±1,5
dBm @ MCS11 40 MHz 18±1.5 dBm @ MCS0 80 MHz 17±1.5 dBm @ MCS11 80 MHz
|
Transmitter Power for 802.11b (Dual Chain) |
- 18±1.5 dBm @ 1 Mbps
18±1.5 dBm @ 11 Mbps
|
Transmitter Power for 802.11g (Dual Chain) |
- 18±1.5 dBm @ 6 Mbps
18±1.5 dBm @ 54 Mbps
|
Transmitter Power for 802.11n (2.4 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS7 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS7 40 MHz
|
Transmitter Power for 802.11ac (2.4 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS8 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS7 40 MHz
|
Transmitter Power for 802.11ax (2.4 GHz, Dual Chain) |
- 18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS11 20 MHz 18±1.5 dBm @ MCS0 40 MHz 18±1.5
dBm @ MCS11 40 MHz
|
Receiver Sensitivity for 802.11a (measured at 5.680 GHz) |
- Typ. -88 @ 6 Mbps
Typ. -72 @ 54 Mbps
|
Receiver Sensitivity for 802.11n (5 GHz; measured at 5.680 GHz) |
- Typ. -88 dBm @ MCS0 20 MHz
Typ. -68 dBm @ MCS7 20 MHz Typ. -84 dBm @ MCS0 40 MHz
Typ. -66 dBm @ MCS7 40 MHz
|
Receiver Sensitivity for 802.11ac (5 GHz) |
- Typ. -88 dBm @ MCS0 20 MHz
Typ. -65 dBm @ MCS8 20 MHz Typ. -85 dBm @ MCS0 40 MHz
Typ. -60 dBm @ MCS9 40 MHz Typ. -81 dBm @ MCS0 80 MHz Typ. -55 dBm @ MCS9 80 MHz
|
Receiver Sensitivity for 802.11ax (5 GHz) |
- Typ. -88 dBm @ MCS0 20 MHz
Typ. -59 dBm @ MCS11 20 MHz Typ. -85 dBm @ MCS0 40 MHz
Typ. -56 dBm @ MCS11 40 MHz Typ. -81 dBm @ MCS0 80 MHz Typ. -52 dBm @ MCS11 80 MHz
|
Receiver Sensitivity for 802.11b (measured at 2.437 GHz) |
- Typ. -96 dBm @ 1 Mbps
Typ. -88 dBm @ 11 Mbps
|
Receiver Sensitivity for 802.11g (measured at 2.437 GHz) |
- Typ. -90 dBm @ 6 Mbps
Typ. -74 dBm @ 54 Mbps
|
Receiver Sensitivity for 802.11n (2.4 GHz; measured at 2.437 GHz) |
- Typ. -90 dBm @ MCS0 20 MHz
Typ. -70 dBm @ MCS7 20 MHz Typ. -87 dBm @ MCS0 40 MHz
Typ. -69 dBm @ MCS7 40 MHz
|
Receiver Sensitivity for 802.11ac (2.4 GHz) |
- Typ. -90 dBm @ MCS0 20 MHz
Typ. -66 dBm @ MCS6 20 MHz Typ. -87 dBm @ MCS0 40 MHz
Typ. -63 dBm @ MCS9 40 MHz
|
Receiver Sensitivity for 802.11ax (2.4 GHz) |
- Typ. -90 dBm @ MCS0 20 MHz
Typ. -59 dBm @ MCS11 20 MHz Typ. -87 dBm @ MCS0 40 MHz
Typ. -56 dBm @ MCS11 40 MHz
|
WLAN Operation Mode |
- Access point
Master Sniffer
|
Antenna |
- External, 2/2 dBi
Omni-directional
|
