SN4141/2JS2JO4V/EUI – SmartNode VoIP Gateway, 2 FXS, 2 FXO

EUI – SmartNode VoIP Gateway, 2 FXS, 2 FXO, 4 VoIP Calls or 4 SIP-SIP Calls (SIP B2BUA), Upgradable (Ma
by PATTON

SN4141_2JS2JO4V_EUI_SUMMARY.html

Up to 8 Analog interfaces (FxS/FxO) - 2, 4 or 8 Analog ports. Either FxS or FxO or a combo configuration. Up to 8 G.722/G.711 or T.38 calls simultaneously.
Advanced Local Call Switching - Virtual interfaces and routing tables provide industry leading flexibility in call handling programming.
Local call switching, soft fallback to alternative routes.
Simultaneously connects to multiple SIP services/IP PBxs.
Network Monitoring - Embedded Patton Cloud network monitoring 24x7.
Management & Provisioning - Web Wizard for ease of use, SNMPv3, TR-069, command line interface, secure zero-touch provisioning, separate config. domain, secure provisioning of configuration and software.
Proprietary OS - Utilizes proprietary Trinity™ software for enhanced security.
Full VoIP protocol support - SIPv2, SIPv2 over TLS**, T.38, G.722 HD voice, RTP security with SRTP**, fax and modem bypass, DTMF relay.
Survivability & Local Breakout - Resiliency or local breakout for the enterprise thanks to onboard FxO ports.
Optional eSBC upgrade for FxS VoIP Gateways with 2 Ethernet Ports - Models containing "SN4141/2ETH" can be converted into high performance enterprise session border controllers (eSBC) simply by purchasing a software license. This capability prepares your voice network for next-generation SIP services and security. For details about the upgraded SN4141 eSBC's capabilities, refer to the model SN5541 eSBC specifications.

Why SmartNode™?

Patton Quality
Made in the USA
Unrivalled Customer Support
FREE Support and Upgrades

Description
Specification
Datasheet

SN4141_2JS2JO4V_EUI_DESCRIPTION.html The SmartNode SN4141-2JS2JO4V-EUI - Series of VoIP Media Gateways support up to eight phone or fax calls. The SN4140 is the perfect choice for All-IP applications where either old, non-replaceable telephones have to be integrated into a UCC environment, or for good old fax devices to be migrated to the next-generation network infrastructure.

The SmartNode 4140 Series of VoIP Media Gateways support up to eight phone or fax calls. The SN4140 is the perfect choice for All-IP applications where either old, non-replaceable telephones have to be integrated into a UCC environment, or for good old fax devices to be migrated to the next-generation network infrastructure.

Patton's™ SmartNode 4140 Series delivers the legacy phone interfaces, service transparency, and flexible integration required for All-IP networks. Patton's™ SmartNode 4140 Series delivers the legacy phone interfaces, service transparency, and flexible integration required for All-IP networks.Patton's™ SmartNode 4140 Series delivers the legacy phone interfaces, service transparency, and flexible integration required for All-IP networks.

SN4141_2JS2JO4V_EUI.html

Number of Calls:	Default Configuration	Max possible (upgradeable)	License SKU
Transcoded SIP to SIP calls	none	4	SNSW-TC
SIP to SIP calls (same codecs)	4	200	SNSW-1B
Voice channels	2, 4, 8*	N/A	N/A
	*depending on model

Capacity	Up to 8 simultaneous low- bandwidth voice or HD calls with SRTP or T.38 fax calls
Voice Signaling	SIPv2 / SIPv2 over TLS** (B2BUA capable, multi instance, simultaneous support of multiple registrars and direct IP dialing) SIPv2 over IPv6 SIP call transfer, redirect DTMF in-band & out-of-band All tones programmable (dial, ringing, busy)
Voice Processing	G.722 G.711m/A-law G.723.1 (6.4 kbps) G.729, 729a, 729ab (8 kbps) G.726 (16 ,24, 32, 40 Kbps) AMR-NB (4.75, 5.15, 5.9, 6.7, 7.4, 7.95, 10.2, 12.2kbps) iLBC at 13.33 kbps (SIP-SIP only) G.168-2004 echo cancellation (128 ms) Up to 8 simultaneous low-bandwidth voice or T.38 fax calls Up to 8 HD calls with SRTP Up to 200 SIP to SIP calls Up to 4 SIP transcoded calls Silence suppression and comfort noise Adaptive and configurabledejitter buffer Configurable RTP packet length
Call Switching and Services	Regular expression based call routing and number manipulation Number blocking Short-dialing Digit collection, distribution and hunt groups Transparent line extension Fallback Routing: Soft fall back to alternative route(s)
FxS Connectivity	2-wire Loopstart on RJ-11/12 EuroPOTS (ETSI EG201188) Programmable AC impedance, feeding, ring and onhook voltage Caller-ID FSK and ITU V.23/Bell 202 generation Long Reach FxS - 10 km @ 3REN load - 24AWG wire (0.205mm2) Secondary Surge Protection (optional)
FxO Connectivity	2-wire Loopstart - RJ11/12 Programmable impedance Ring detection, tone detection Caller ID detection (FxS, DTMF) Disconnect supervision
Connectivity	One or two 10/100/1000Base-T Ethernet ports USB 2.0 host port (/2ETH port version only) Auto-MDIx DHCP Client PPPoE Client (multi-session) IP Multi-Netting, VLAN, Secondary IP IPv4 and IPv6 - Dual Stack ICMP Dynamic and static NAT and NAPT ACL, Stateful Firewall DNS, DynDNS DHCP Server SNTP Client
Quality of Service	Patton Cloud network monitoring Voice priority, DownStreamQoS™ Traffic Management, shaping policing IEEE 802.1p, IEEE 802.1Q, 4096 VLANs (Tag insertion/deletion), TOS, DiffServ Labeling
Management	Patton Cloud Orchestrated Customizable WebWizard, Web-based GUI, CLI Telnet and HTTP access TR-069, TFTP, HTTP, HTTPS configuration up- and download TR-069, TFTP, HTTP, HTTPS firmware upgrade, Dual Image SNMPv3 agent - MIB II and private MIB Separate config domain (LAN side config and WAN side config) Built-in diagnostic tools Secure Auto-Provisioning with built in root CA
Power Consumption	< 10W
Packaging	Desktop/Wall-mount plastic chassis
Dimensions	8.2W x 1.3H x 6.5D in. (20.8W x 3.4H x 16.5D cm)
Weight	< 450g (15.9 oz)
Environment	Operating temperature: 32 to 104°F (0 to 40°C) Operating humidity: up to 90%, non-condensing) Industrial version available SN4141E
Safety & Compliance	EMC compliance: EN55022 and EN55024 Safety compliance: EN 60950 CE compliance FCC Part 15 Class A TBR21 (FxS) RoHS ITU-T K.21 protection (FxS ports)
