CPU |
Intel® Core™ i3-12100 4-core/8-thread Processor, burst up to 4.3 GHz |
CPU Architecture |
64-bit x86 |
Graphic Processors |
Intel® UHD Graphics 730 |
Floating Point Unit |
|
Encryption Engine |
(AES-NI) |
Hardware-accelerated Transcoding |
|
System Memory |
16 GB SODIMM DDR4 (1 x 16 GB) |
Maximum Memory |
64 GB ( 2 x 32 GB) |
Memory Slot |
2 x SODIMM DDR4 |
Flash Memory |
5GB (Dual boot OS protection) |
Drive Bay |
6 x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
|
Hot-swappable |
|
M.2 Slot |
2 x M.2 2280 PCIe Gen 4 x4 slots
|
SSD Cache Acceleration Support |
|
GPU pass-through |
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via PCIe expansion card |
10 Gigabit Ethernet Port |
Optional via PCIe expansion card Optional via PCIe expansion card
|
Wake on LAN (WOL) |
|
Jumbo Frame |
|
PCIe Slot |
2 Slot 1: PCIe Gen 4 x16 Slot 2: PCIe Gen 4 x4 Card
dimensions for PCIe slot 1~Slot 2:185 x 111.15 x 18.76 mm / 7.28 x 4.38 x 0.74 inches. Wider
cards can be installed if the next PCIe slot will not be used.
|
USB 3.2 Gen 2 (10Gbps) Port |
1 x Type-C USB 3.2 Gen 2 10Gbps 2 x Type-A USB 3.2 Gen 2 10Gbps |
HDMI™ Output |
1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
Form Factor |
Tower |
LED Indicators |
HDD 1-6, Status, LAN, USB port, M.2 port |
LCD Display/ Button |
|
Buttons |
Power, Reset, USB Copy |
Dimensions (HxWxD) |
7.09 x 10.41 x 11.01 inch Dimensions do not include foot pad (foot
pad may be up to 30mm / 1.18 inches high depending on model)
|
Weight (Net) |
13.93 lbs |
Weight (Gross) |
17.39 lbs |
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
Power Supply Unit |
250W, 100-240V |
Power Consumption: HDD Sleep Mode |
39.911 W |
Power Consumption: Operating Mode, Typical |
79.363 W Tested fully populated with WD10EFRX hard drives.
|
Fan |
System fan: 2 x 92mm, 12VDC CPU fan: 1 x 60mm, 12VDC |
System Warning |
Buzzer |
Kensington Security Slot |
|
Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
2500 |
