CPU |
AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor |
CPU Architecture |
64-bit x86 |
Floating Point Unit |
|
Encryption Engine |
(AES-NI) |
System Memory |
32 GB SODIMM DDR4 (2 x 16 GB) |
Maximum Memory |
64 GB (2 x 32 GB) |
Memory Slot |
2 x SODIMM DDR4 Support optional ECC memory For dual-DIMM
configuration, you must use a pair of identical DDR4 modules.
|
Flash Memory |
5GB (Dual boot OS protection) |
Drive Bay |
5 x 3.5-inch + 4 x 2.5-inch
|
Drive Compatibility |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA hard disk drives 2.5-inch
SATA solid state drives 2.5-inch U.2 NVMe PCIe Gen3 x4 solid state drives (2.5-inch Bay #1 & #2)
* 2.5-inch bay #1 & #2 support either U.2 NVMe SSDs or SATA 6Gb/s SSDs. **
U.2 NVMe solid-state drives can only be installed in 2.5-inch bay numbers 1 and 2. Installing these
drives in other bays will damage the drive connectors.
|
Hot-swappable |
|
SSD Cache Acceleration Support |
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M) |
5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via the QNA-UC5G1T USB to 5GbE network adapter |
10 Gigabit Ethernet Port |
1 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
Wake on LAN (WOL) |
|
Jumbo Frame |
|
USB 3.2 Gen 2 (10Gbps) Port |
1 x Type-C USB 3.2 Gen 2 3 x Type-A USB 3.2 Gen 2 |
Form Factor |
Tower |
LED Indicators |
HDD 1-5, SSD 1-4, Power/Status, LAN, USB |
Buttons |
Power, Reset, USB Copy |
Dimensions (HxWxD) |
6.95 x 8.84 x 8.82 inch Dimensions do not include foot pad (foot pad
may be up to 30mm / 1.18 inches high depending on model)
|
Weight (Net) |
9.57 lbs |
Weight (Gross) |
11.2 lbs |
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
Power Supply Unit |
External, 120 W, AC 100 to 240 V |
Power Consumption: HDD Sleep Mode |
41.2 W |
Power Consumption: Operating Mode, Typical |
55.41 W Tested with drives fully populated.
|
Fan |
1 x 140mm, 12VDC |
System Warning |
Buzzer |
Kensington Security Slot |
|
Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
2000 |
