| CPU |
Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Intel® UHD Graphics |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
|
| System Memory |
8 GB RAM |
| Maximum Memory |
8 GB |
| Flash Memory |
4GB (Dual boot OS protection) |
| Drive Bay |
4 x 3.5-inch SATA 6Gb/s
|
| Drive Compatibility |
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| M.2 Slot |
2 x M.2 2280 PCIe Gen 3 x1
|
| SSD Cache Acceleration Support |
|
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
| 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via PCIe expansion card |
| 10 Gigabit Ethernet Port |
Optional via PCIe expansion card |
| Wake on LAN (WOL) |
|
| Jumbo Frame |
|
| PCIe Slot |
1
Slot 1: PCIe Gen 3 x2 Card dimensions for PCIe slot: 190 x
68.9x 18.76 mm / 7.48 x 2.71 x 0.74 inches.
|
| USB 2.0 port |
2 |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-A |
| IR Sensor |
(Optional QNAP RM-IR004 remote control)
|
| HDMI™ Output |
1, HDMI™ 2.1 (up to 4096 x 2160 @ 60Hz) |
| Form Factor |
Tower |
| LED Indicators |
Power/Status, LAN, USB, HDD1-4 |
| Buttons |
Power, USB copy, Reset |
| Dimensions (HxWxD) |
6.5 x 6.69 x 8.92 inch Dimensions do not include foot pad (foot pad
may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) |
4.98 lbs |
| Weight (Gross) |
7.91 lbs |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
90W adapter, 100-240V |
| Power Consumption: HDD Sleep Mode |
21.618 W |
| Power Consumption: Operating Mode, Typical |
40.536 W Tested with drives fully populated.
|
| Fan |
1 x 120mm, 12VDC |
| System Warning |
Buzzer |
| Kensington Security Slot |
|
| Standard Warranty |
3 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
1500 |
