| CPU |
Intel® Xeon® E-2336 6C 12T 2.9GHz, up to 4.8GHz |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Optional via a PCIe adapter |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| System Memory |
32 GB ECC DDR4 (1 x 32 GB) |
| Maximum Memory |
128GB (4 x 32 GB) |
| Memory Slot |
4 x ECC UDIMM DDR4 For dual-DIMM configuration, you must use a pair
of identical DDR4 modules.
|
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
18 (12 x 3.5-inch SATA + 6 x 2.5-inch SATA) |
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA solid state
drives
2.5-inch bays:
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| M.2 Slot |
Optional via a QM2 PCIe adapter |
| SSD Cache Acceleration Support |
|
| GPU pass-through |
|
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M) |
| 10 Gigabit Ethernet Port |
2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| 25 Gigabit Ethernet Port |
Optional via a PCIe adapter |
| Wake on LAN (WOL) |
|
| PCIe Slot |
3 (2 x Gen4 x4 +1 x Gen 4 x8) Card dimensions for PCIe slot 1：250 x
68.9 x 23.76 mm / 6.70 x 2.71 x 0.94 inches.
Card dimensions for PCIe slot 2：250 x 68.9 x 18.76
mm / 6.70 x 2.71 x 0.74 inches.
Card dimensions for PCIe slot 3：250 x 68.9 x 18.76 mm / 6.70 x
2.71 x 0.74 inches.
Wider cards can be installed if the next PCIe slot will not be used.
|
| USB 3.2 Gen 2 (10Gbps) Port |
4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
| HDMI™ Output |
Optional via a PCIe adapter |
| Form Factor |
2U Rackmount |
| LED Indicators |
Status (Green/Red)
LAN (Green)
USB (Blue)
HDD status (Green/Red) |
| Buttons |
Power, Reset |
| Dimensions (HxWxD) |
3.49 x 17.01 x 20.13 inch |
| Weight (Net) |
32.78 lbs |
| Weight (Gross) |
41.89 lbs |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5~95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
2 x 550W PSU |
| Power Consumption: HDD Sleep Mode |
118.77 W |
| Power Consumption: Operating Mode, Typical |
148.94 W |
| Fan |
4 x 60mm, 12VDC |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
11000 |
