CPU |
Intel® Xeon® E-2334 4C 8T 3.4GHz, up to 4.8GHz |
CPU Architecture |
64-bit x86 |
Graphic Processors |
Optional via a PCIe adapter |
Floating Point Unit |
|
Encryption Engine |
(AES-NI) |
System Memory |
16 GB ECC DDR4 (1 x 16 GB) |
Maximum Memory |
128GB (4 x 32 GB) |
Memory Slot |
4 x ECC UDIMM DDR4 For dual-DIMM configuration, you must use a pair
of identical DDR4 modules.
|
Flash Memory |
5GB (Dual boot OS protection) |
Drive Bay |
18 (12 x 3.5-inch SATA + 6 x 2.5-inch SATA) |
Drive Compatibility |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state
drives 2.5-inch bays: 2.5-inch SATA solid state drives |
Hot-swappable |
|
M.2 Slot |
Optional via a QM2 PCIe adapter |
SSD Cache Acceleration Support |
|
GPU pass-through |
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M) |
10 Gigabit Ethernet Port |
2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
25 Gigabit Ethernet Port |
Optional via a PCIe adapter |
Wake on LAN (WOL) |
|
PCIe Slot |
3 (2 x Gen4 x4 +1 x Gen 4 x8) Card dimensions for PCIe slot 1:250 x
68.9 x 23.76 mm / 6.70 x 2.71 x 0.94 inches. Card dimensions for PCIe slot 2:250 x 68.9 x 18.76
mm / 6.70 x 2.71 x 0.74 inches. Card dimensions for PCIe slot 3:250 x 68.9 x 18.76 mm / 6.70 x
2.71 x 0.74 inches. Wider cards can be installed if the next PCIe slot will not be used.
|
USB 3.2 Gen 2 (10Gbps) Port |
4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
HDMI™ Output |
Optional via a PCIe adapter |
Form Factor |
2U Rackmount |
LED Indicators |
Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red) |
Buttons |
Power, Reset |
Dimensions (HxWxD) |
3.49 x 17.01 x 20.13 inch |
Weight (Net) |
32.78 lbs |
Weight (Gross) |
41.89 lbs |
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
Relative Humidity |
5~95% RH non-condensing, wet bulb: 27°C (80.6°F) |
Power Supply Unit |
2 x 550W PSU |
Power Consumption: HDD Sleep Mode |
118.77 W |
Power Consumption: Operating Mode, Typical |
148.94 W |
Fan |
4 x 60mm, 12VDC |
Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
11000 |
