| CPU |
Intel® Xeon® D-1622 4-core processor, burst up to 3.2 GHz |
| CPU Architecture |
64-bit x86 |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| System Memory |
32 GB UDIMM DDR4 ECC (2 x 16GB) |
| Maximum Memory |
128 GB (4 x 32 GB) |
| Memory Slot |
4 x UDIMM DDR4 |
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
Front: 12 x 3.5-inch SATA 6Gb/s, 3Gb/s
Rear: 6 x 2.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA solid state
drives
2.5-inch bays:
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| SSD Cache Acceleration Support |
|
| SR-IOV |
|
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
4 (2.5G/1G/100M) |
| 10 Gigabit Ethernet Port |
2 x 10GbE SFP+ SmartNIC port Pre-installed with a 10GbE PCIe adapter
|
| Wake on LAN (WOL) |
|
| Jumbo Frame |
|
| PCIe Slot |
3
Slot 1: PCIe Gen 2 x4 (x8 Slot)
Slot 2: PCIe Gen 3 x4
Slot 3: PCIe Gen 3 x8
or x4 (x8 Slot) *Slot 3 is preinstalled with a 10GbE network adapter.
**Slot 3
provides the width of PCIe Gen 3 x8 when Slot 2 is not in use, and provides the width of PCIe Gen 3
x4 when Slot 2 is in use.
Card dimensions for PCIe slot 1：170 x 68.9 x 39.08 mm / 6.70 x 2.71 x
1.54 inches.
Card dimensions for PCIe slot 2：170 x 68.9 x 18.76 mm / 6.70 x 2.71 x 0.74
inches.
Card dimensions for PCIe slot 3：170 x 68.9 x 18.76 mm / 6.70 x 2.71 x 0.74 inches.
Wider cards can be installed if the next PCIe slot will not be used.
|
| USB 3.2 Gen 1 port |
2 |
| Form Factor |
Rackmount |
| LED Indicators |
HDD, SSD, Status, LAN, storage expansion port status |
| Buttons |
Power, Reset |
| Dimensions (HxWxD) |
3.49 x 17.01 x 20.13 inch |
| Weight (Net) |
31.97 lbs |
| Weight (Gross) |
41.01 lbs |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
550W(x2), 100-240V |
| Power Consumption: Operating Mode, Typical |
117.92 W Tested with drives fully populated.
|
| Fan |
System fan: 3 x 60mm, 12VDC |
| System Warning |
Buzzer |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
10000 |
