TP-VR-2409 * discontinued * Last 8 available - Voltage Regulator 12-32VDC input, 9V @ 1.66A regulated output. 15W. 12' 18AWG lea by Tycon Systems

TP-VR-2409 * discontinued * Last 8 available - Voltage Regulator 12-32VDC input, 9V @ 1.66A regulated output. 15W. 12" 18AWG lea
by Tycon Systems

Write a review Write a review

** Minimum Order Quantity: 10 **

  • Compact Size , Sealed Design
  • High Output , Short Circuit Protected
  • 12" 18AWG Lead Wires



Mfg SKU # : TP-VR-2409
Minimum Qty : 10
Our Price : $22.95
Stock : Call for Availability
Quantity :

The TP-VR-2409 is a 15W voltage converter/regulator which accepts an input of 12VDC to 32VDC and provides a regulated output of 9VDC @ 1.66A 15W. These units are perfect for providing stable regulated 9VDC voltage from 12VDC or 24VDC battery banks. Excellent for vehicular and remote power applications.

DC Input Voltage Range 18V to 32VDC
DC Voltage Output 9VDC @ 1.66A
Maximum Power Dissipation 15W
Efficiency 80%
Load / Line Regulation 5% / 1%
Ripple / Noise 2% / 5%
Wire Gauge 18AWG
Lead Wire Length 12"
Operating Temperature - 40°F to 149°F ( - 40°C to +65°C)
Operating Humidity 0 to 99% RH
Size 2.75 x 1.25 x 1” (70x32x25mm)
Weight 1.5oz (43g)
Warranty 2 Years
