| Physical Ports |
|
|
| 10/100Base-T(X) Ports in RJ45 Auto MDI/MDIX |
2 |
|
| Fiber Ports Number |
1 |
|
| Fiber Ports Standard |
100Base -FX |
|
| Fiber Mode |
Multi-mode |
|
| Fiber Diameter (μm) |
62.5/125 μm 50/125 μm |
|
| Fiber Optical Connector |
SC |
|
| Typical Distance (km) |
2 km |
|
| Wavelength (nm) |
1340 dBm |
|
| Max. Output Optical Power (dBm) |
-14 dBm |
|
| Min. Output Optical Power (dBm) |
-31 dBm |
|
| Max. Input Optical Power(Saturation) |
0 dBm |
|
| Min. Input Optical Power(Sensitivity) |
-31 dBm |
|
| Link Budget (dB) |
7.5 dB |
|
| WLAN
interface |
|
|
| Ethernet Standards |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX and 100Base-FX |
| LED Indicators |
|
|
| 10/100Base-T(X) RJ45 Port Indicator |
Green : Power LED x 2 |
| 100Base-FX Fiber Port Indicator |
Green for port Link/Act. Amber for Duplex/Collision |
| Power |
|
|
| Redundant Input Power |
Dual 12~48 VDC power input at 4-pin terminal block |
| Power Consumption (Typ.) |
4.5 Watts |
|
| Overload Current Protection |
Present |
|
| Reverse Polarity Protection |
Present |
|
| Physical Characteristics |
|
|
| Enclosure |
IP-30 |
|
| Dimensions (W x D x H) |
26.1 (W) x 70 (D) x 95 (H)mm (1.03 x 2.76 x 3.74 inch) |
| Weight (g) |
210 g |
|
| Environmental |
|
|
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
|
| Operating Temperature |
-40 to 70°C (-40 to 158°F) |
|
| Operating Humidity |
5% to 95% Non-condensing |
|
| Regulatory Approvals |
|
|
| EMI |
FCC Part 15, CISPR (EN55022) class A, |
| EMS |
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT),
EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11 |
| Shock |
IEC60068-2-27 |
|
| Free Fall |
IEC60068-2-32 |
|
| Vibration |
IEC60068-2-6 |
|
| Safety |
EN60950-1 |
|
| Warranty |
5 years |
