ICP DAS CAN-2018C - 8 Channel Thermocouple Input
by ICP DAS
|
|
|
|
CANopen Slave Module of 8-channel Thermocouple Input (Analog Input), Current Input
|
|
|
Following the DS-301 version 4.02 and DSP-401 version 2.1, the CAN-2018C module allows access to thermocouple input status and configuration settings through standard CANopen protocol. CAN-2018C has passed the validation of the CiA CANopen Conformance Test tool. This device can be used with standard CANopen master through use of the EDS file.
The CAN-2018C is a 10-channel universal analog input CANopen slave module that has voltage and current input types. It provides extremely accurate thermocouple measurement and automatic cold-junction compensation for each channel.

| CANopen Interface |
| NMT |
Slave |
| Error Control |
Node Guarding protocol / Heartbeat Producer |
| No. of PDOs |
10Rx , 10Tx |
| PDO Modes |
Event Triggered, Remotely requested, Cyclic and acyclic SYNC |
| PDO Mapping |
Available |
| No. of SDOs |
1 server, 0 client |
| Emergency Message |
Yes |
| CANopen Version |
DS-301 v4.02 |
| Device Profile |
DSP-401 v2.1 |
| Specification |
ISO-11898-2, CAN 2.0A and CAN 2.0B |
Baud Rate (bps)
Setting by Rotary Switch |
10 k, 20 k, 50 k, 125 k, 250 k, 500 k, 800 k, and 1 M |
Node ID
Setting by Rotary Switch |
1 ~ 99 |
| Terminator Resistor |
Switch for 120 Ω terminator resistor |
| Connector |
5-pin screwed terminal block (CAN_GND, CAN_L, CAN_SHLD, CAN_H, CAN_V+) |
| EDS file |
Yes |
| Analog Input |
| Channels |
8 |
| Input Type |
+/- 15mV, +/- 50mV, +/- 100mV, +/- 500mV, +/- 1V, +/- 2.5V
+/-20mA,(Requires Optional External 125 Ohm Resistor)
Thermocouple (J, K, T, E, R, S, B, N, C) |
| Resolution |
16-bit |
| Sampling Rate |
10 Samples/Sec. (Total) |
| Accuracy |
+/-0.1% FSR |
| Zero Drift |
+/- 10 μV/ °C |
| Span Drift |
+/- 25 ppm/ °C |
| Common Mode Rejection |
86 dB |
| Normal Mode Rejection |
100 dB |
| Input Impedance |
>400 kΩ |
| Individual Channel Configuration |
Yes |
| Open Thermocouple Detection |
Yes |
| Over voltage Protection |
240 Vrms |
| ESD Protection |
+/-4kV, Contact for each terminal. |
| Intra-module Isolation, Field to Logic |
3000 VDC |
| LED |
| Power |
PWR, red |
| CANopen Status |
RUN/ERR, green/orange |
| Power |
| Power Supply |
Unregulated +10 ~ +30 VDC |
| Power Consumption |
1.5 W |
| Mechanism |
| Installation |
DIN-Rail |
| Dimensions |
32.3 mm x 99 mm x 77.5 mm ( W x L x H ) |
| Environment |
| Operating Temp. |
-25 ~ 75 ℃ |
| Storage Temp. |
-30 ~ 80 ℃ |
| Humidity |
10 ~ 90% RH, non-condensing |
| Type Code |
Temperature Range (°C) |
| J |
-210 °C ~ +1200 °C |
| K |
-270 °C ~ +1372 °C |
| T |
-270 °C ~ +400 °C |
| E |
-270 °C ~ +1000 °C |
| R |
-50 °C ~ +1765 °C |
| S |
-50 °C ~ +1765 °C |
| B |
0 °C ~ +1820 °C |
| N |
-270 °C ~ +1300 °C |
| C |
0 °C ~ +2320 °C |
|
|
|
|
