| Digital Output |
| Output Channels |
4 |
| Output Type |
Power Relay, Form C |
| Relay Contact Voltage Range |
5A(NO)/3A(NC)@30VDC |
| 5A(NO)/3A(NC)@277VAC |
| Max. load Current |
5A(NO)/3A(NC) at 65°C |
| Max. Operate Time |
10 ms Max. |
| Max. Release Time |
5 ms Max. |
| Insulation Resistance |
Min. 100 M Ohm, at 500VDC |
| Dielectric Strength |
Between Open Contacts : 500Vrms (at 1 Minute) |
| Between Coil and Contacts : 1000Vrms (at 1 Minute) |
| Relay Life |
Mechanical : 100,000,000 min. |
| Electrical : 500, 000 Min. at 30VDC@2A, Resistive |
| 4KV ESD Protection |
contact for each channel |
| LED Display |
| 1 LED as Power Indicator |
| 8 LEDs as Digital Input and Relay output Indicators |
| Power |
| Power Consumption |
0.4A @ 5V = 2W, +/- 5% For Hardware |
| Environment |
| Operating Temperature |
-25 to 75 °C |
| Storage Temperature |
-30 to 85 °C |
| Humidity |
5 to 95% RH, non-condensing |
| Dimensions |
| 30mm x 102mm x 115mm (W x L x H) |
