| • Interface |
| Fiber Ports |
100/1000BaseSFP slot |
| RJ45 Ports |
10/100/1000BaseT(X) auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection |
| PoE+ Ports |
10/100/1000BaseT(X) auto negotiation speed, compliant with IEEE 802.3af/at high power mode up to 36 W |
| LED Indicators |
STAT, 10/100/1000 for TP port, 100/1000 for fiber port |
| Hot Swap Button |
Push this button prior to swapping IM-G7000A modules |
| • Power Requirements |
| Power Consumption |
IM-G7000A-4GTX: 4.1 W
IM-G7000A-4GSFP: 3.3 W
IM-G7000A-4PoE: 6.07 W (without PD power consumption) |
| NOTE |
The IM-G7000A-4PoE must be connected to a 48 VDC external power supply to provide power to PoE devices. |
| • Physical Characteristics |
| Housing |
IP30 protection |
| Dimensions |
28.8 x 174.7 x 166.8 mm (1.13 x 6.88 x 6.57 in) |
| Weight |
220 g |
| • MTBF (mean time between failures) |
| Time |
IM-G7000A-4GTX: 1,569,520 hrs
IM-G7000A-4GSFP: 1,544,084 hrs
IM-G7000A-4PoE: 394,348 hrs |
