| CPU |
Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Intel® UHD Graphics |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
|
| System Memory |
8 GB RAM |
| Maximum Memory |
8 GB |
| Flash Memory |
4GB (Dual boot OS protection) |
| Drive Bay |
4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| M.2 Slot |
2 x M.2 2280 PCIe Gen 3 x1 slots
|
| SSD Cache Acceleration Support |
|
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
| Wake on LAN (WOL) |
|
| Jumbo Frame |
|
| USB 2.0 port |
2 |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type A USB 3.2 Gen 2 |
| HDMI™ Output |
1, HDMI™ 1.4b |
| Form Factor |
1U Short Depth Rackmount |
| LED Indicators |
Power/Status, LAN, USB, HDD1-4, M.2 SSD 1-2 |
| Buttons |
Power, Reset |
| Dimensions (HxWxD) |
1.7 x 16.93 x 11.5 inch |
| Weight (Net) |
10.93 lbs |
| Weight (Gross) |
13.01 lbs |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
100W PSU, 100-240V |
| Power Consumption: HDD Sleep Mode |
21.105 W |
| Power Consumption: Operating Mode, Typical |
35.297 W Tested with drives fully populated.
|
| Fan |
3 x 40mm |
| System Warning |
Buzzer |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
1500 |
