| CPU |
ARM 4-core Cortex-A55 2.0GHz processor |
| CPU Architecture |
64-bit ARM |
| Graphic Processors |
Mali-G52 |
| Floating Point Unit |
|
| Encryption Engine |
|
| Hardware-accelerated Transcoding |
|
| Neural Processing Unit (NPU) |
|
| System Memory |
2 GB on board (non-expandable) Note: Reserves some RAM for use as
shared graphics memory.
|
| Maximum Memory |
2 GB on board (non-expandable) |
| Flash Memory |
4 GB (Dual boot OS protection) |
| Drive Bay |
2 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| Gigabit Ethernet Port (RJ45) |
1 |
| Wake on LAN (WOL) |
|
| Jumbo Frame |
|
| USB 2.0 port |
2 |
| USB 3.2 Gen 1 port |
1 |
| Form Factor |
Tower |
| LED Indicators |
System Status, LAN, USB, HDD1~2 |
| Buttons |
Power, Reset, USB Copy |
| Dimensions (HxWxD) |
7.32 x 3.61 x 6.2 inch Dimensions do not include foot pad (foot pad
may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) |
3.73 lbs |
| Weight (Gross) |
4.17 lbs |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
Minimum 48W adapter (12VDC), 100-240VAC |
| Power Consumption: HDD Sleep Mode |
3.43 W |
| Power Consumption: Operating Mode, Typical |
10.81 W Tested with drives fully populated.
|
| Fan |
1 x 80mm, 12VDC |
| System Warning |
Buzzer |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
200 |
