| CPU |
Intel® Xeon® D-1602 2-core/4-thread processor, up to 3.2 GHz |
| CPU Architecture |
64-bit x86 |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
Optional via a PCIe adapter |
| System Memory |
8 GB UDIMM DDR4 ECC (2 x 4 GB) |
| Maximum Memory |
128 GB (4 x 32 GB) |
| Memory Slot |
4 x UDIMM DDR4 For dual-DIMM configurations, you must use a pair of
identical DDR4 modules.
|
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
6 x 3.5-inch SATA 6Gb/s, 3Gb/s + 2 x 2.5-inch SATA 6Gb/s, 3Gb/s
|
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
2.5-inch bays:
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| M.2 Slot |
2 x M.2 22110/2280 NVMe PCIe Gen3 x4 slots
|
| SSD Cache Acceleration Support |
|
| GPU pass-through |
|
| SR-IOV |
|
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
4 (2.5G/1G/100M/10M) |
| 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via an adapter |
| 25 Gigabit Ethernet Port |
Optional via an adapter |
| Wake on LAN (WOL) |
Only the 2.5GbE port
|
| Jumbo Frame |
|
| PCIe Slot |
2
Slot 1: PCIe Gen3 x8
Slot 2: PCIe Gen3 x8 Card dimensions
for PCIe slot 1：260 x 111.15 x 37.52 mm / 10.25 x 4.38 x 1.48 inches.
Card dimensions for PCIe
slot 2：150 x 68.9 x 37.52 mm / 5.90 x 2.71 x 1.48 inches.
|
| USB 3.2 Gen 1 port |
3 |
| Form Factor |
Tower |
| LED Indicators |
System status, LAN, USB, Disk 1~8, M.2 SSD 1~2 |
| Buttons |
Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) |
8.86 x 11.53 x 12.59 inch Dimensions do not include foot pad (foot
pad may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) |
22.05 lbs |
| Weight (Gross) |
22.71 lbs |
| Operating Temperature |
0 - 40°C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
250W PSU, 100~240V |
| Power Consumption: Operating Mode, Typical |
75.79 W Tested with drives fully populated.
|
| Fan |
System fan: 2 x 80mm, 12VDC
CPU fan: 1 x 90mm, 12VDC |
| System Warning |
Buzzer |
| Kensington Security Slot |
|
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
10000 |
