ICP DAS WISE-7117 - 8 channel Analog Input and 4 channel Isolated output
by ICP DAS
|
|
|
|
8-channel Analog Input (Current Input) with High Voltage Protection and 4-channel Isolated Digital Output Output PoE Module, web browser configurable, allows users to implement IF-Then Else If type control logic and communicable over Modbus TCP. MiniOS7 Operating System.
|
|
|
WISE (Web Inside, Smart Engine) is a product series developed by ICP DAS that functions as control units for use in remote logic control and monitoring in various industrial applications. WISE offers a user-friendly and intuitive web site interface that allows users to implement IF-THEN-ELSE control logic on controllers just a few clicks away; no programming is required. With its powerful and easy-to-use features, it will minimize the learning curve, shorten time to market and dramatically reduce the effort and cost spent on system development.
WISE-7117 follows IEEE 802.3af-compliant (classification, Class 1) Power over Ethernet (PoE) specification. It allows receiving power from PoE enabled network by Ethernet pairs (Category 5 Ethernet cable). This feature provides greater flexibility and higher efficiency therefore simplifying systems design, saving space, reducing cables and eliminating the requirement for dedicated electrical outlets. Meanwhile, in case under a non-PoE environment, WISE-7117 will still be able to receive power from auxiliary power sources like AC adapters or battery, etc.
This multi-function module WISE-7117 supports Modbus/TCP protocol to make seamless integration with SCADA software available. It features 16-bit, 8-channel differential analog inputs and 4-channel digital ouputs. Each analog channel is allowed to configure an individual range and has 240Vrms high over voltage protection. Jumper selectable for voltage or current input.
- Built-in Web Server for IF-THEN-ELSE rule setting
- Built-in IF-THEN-ELSE rule engine for logic operation
- No more programming. Just click and get done!
- Support IO, Counter, Timer, Email operations
- Modbus/TCP Protocol for SCADA Software Seamless Integration
- IEEE 802.3af-compliant Power over Ethernet (PoE)
- 10/100 Base-TX Ethernet
- AI Type: 8 Differential (mV, V, mA)
- DO Type: 4 Open Collector Outputs
- Over Voltage Protection is up to 240 Vrms
- 2-way Isolation/ESD protection
| Analog Input |
| Input Channels |
8 (Differential) |
| Input Type |
+/-150 mV, +/-500 mV, +/-1V, +/-5V, +/-10V
+/-20 mA, 0 ~ 20 mA, 4 ~ 20 mA (Jumper Selectable) |
| Resolution |
Normal Mode |
16-bit |
| Fast Mode |
12-bit |
| Sampling Rate |
Normal Mode |
10 Samples/Sec.(Total) |
| Fast Mode |
60 Samples/Sec. (Total) |
| Accuracy |
Normal Mode |
+/-0.1% |
| Fast Mode |
+/-0.5% or better |
| Bandwidth |
Normal Mode |
15.7 Hz |
| Fast Mode |
78.7 Hz |
| Zero Drift |
+/-10 μV/°C |
| Span Drift |
+/-25 ppm/°C |
| Input Impedance |
Voltage |
2 MΩ |
| Current |
125 Ω |
| Common Mode Rejection |
86 dB Min. |
| Normal Mode Rejection |
100 dB |
| Individual Channel Configuration |
Yes |
| Over Voltage Protection |
240 Vrms |
| ESD Protection |
+/-4 kV (Contact for each channel)
+/-8 kV air for random point |
| EFT Protection |
+/-4 kV for Power |
| Digital Output |
| Output Channels |
4 (Sink) |
| Output Type |
Isolated Open Collector |
| Max. Load Current |
700 mA/Channel |
| Load Voltage |
5 VDC ~ 50 VDC |
| System |
| CPU |
80186 CPU (80 MHz) |
| SRAM |
512 KB |
| Flash Memory |
512 KB |
| EEPROM |
16 KB |
| Dual Watchdog |
Yes |
| Communication |
| PoE Ethernet Port |
10/100 Base-TX (With Link, Activity LED
Indicator) and automatic MDI/MDI-X |
| 2-way Isolation |
| Ethernet |
1500 VDC |
| AI and DO |
2500 Vrms |
| LED Indicators |
| PoE |
PoE On |
| L1 |
Run |
| L2 |
Link/Act |
| L3 |
10/100 M |
| Power Requirements |
| IEEE 802.3af |
Class 1 |
| Required Supply Voltage |
Powered by Power-Over-Ethernet (PoE) or auxiliary power +12 ~ +48 VDC(non-regulated) |
| LED Indicator |
Yes |
| Power Consumption |
0.12 A @ 24 VDC Max. |
| Mechanical |
| Dimensions (W x H x D) |
72 mm x 123 mm x 35 mm |
| Installation |
DIN-Rail or Wall mounting |
| Environment |
| Operating Temperature |
-25°C ~ +75 °C |
| Storage Temperature |
-30°C ~ +80 °C |
| Relative Humidity |
5 ~ 90% RH, non-condensing |
|
|
|
|
