| • Cellular Interface |
| Standards |
GSM/GPRS/EDGE/UMTS/HSPA/LTE |
| Band Options |
OnCell G3470A-LTE-EU:
• LTE 2100/1800/2600/900/800 MHz (B1/B3/B7/B8/B20)
• UMTS/HSPA 2100/1900/850/800/900 MHz
OnCell G3470A-LTE-US:
• LTE 1900/AWS/850/700/1900 MHz (B2/B4/B5/B13/B17/B25)
• UMTS/HSPA 2100/1900/AWS/850/900 MHz
• Universal Quad-band GSM/GPRS/EDGE 850/900/1800/1900 MHz |
| LTE Data Rate |
• Downlink: 100 Mbps (20 MHz bandwidth), 50 Mbps (10 MHz bandwidth)
• Uplink: 50 Mbps (20 MHz bandwidth), 25 Mbps (10 MHz bandwidth) |
| GPRS Multi-slot Class |
Class 12 |
| HSPA Data Rate |
• Downlink: Up to 42 Mbps (category 24)
• Uplink: Up to 5.76 Mbps (category 6) |
| GPRS Data Rate |
236 kbps Downlink/Uplink, Class 12 |
| • LAN Interface |
| Number of Ports |
4 |
| Ethernet |
10/100/1000 Mbps, RJ45 connector, Auto MDI/MDIX |
| • Interface |
| Alarm Contact |
1 relay output with current carrying capacity of 1 A @ 24 VDC |
| Console Port |
RS-232 (RJ45) |
| Ethernet |
2 SMA (female) |
| Digital Inputs |
2 electrically isolated inputs
+13 to +30 V for state “1”
+3 to -30 V for state “0” |
| GNSS |
1 SMA (female), GPS (1575.42 MHz), GLONASS (1602 MHz) |
| LED Indicators |
PWR1, PWR2, READY, FAULT, CELLULAR SIGNAL, SIM1, SIM2, 2G, 3G, 4G, GPS |
| Ground Screw |
M5 |
| Reset Button |
Power Reset/Factory Default Reset |
| • Software |
| Network Protocols |
ICMP, TCP/IP, UDP, DHCP, Telnet, DNS, SNMP, HTTP, HTTPS, SMTP, SNTP, ARP |
| Routing/Firewall |
NAT, Port Forwarding, IP/MAC/Port Filtering |
| VPN |
Max. Tunnel Number: 5 (Responder/Initiator)
IPSec (DES, 3DES, AES, MD5, SHA-1, DH2, DH5), PSK/X.509/RSA |
| Cellular Connectivity |
GuaranLink |
| GPS |
NMEA |
| Others |
DDNS |
| • Management Software |
| Utilities |
OnCell Search Utility |
| Configuration and Management Options |
Remote SMS Control, SNMPv1/v2c/v3, Web/Telnet/Serial Console |
| Private IP Solution |
OnCell Central Manager |
| • SIM Interface |
| Number of SIMs |
2 |
| SIM Control |
3 V |
| • Physical Characteristics |
| Housing |
Aluminum, providing IP30 protection |
| Weight |
1300 g |
| Installation |
DIN-rail (default) or wall-mount (optional) |
| Dimensions |
67 x 90.5 x 124 mm (2.6 x 3.52 x 4.83 inch) |
| • Environmental Limits |
| Operating Temperature |
Standard Models: -30 to 55°C (-22 to 131°F)
Wide Temp. Models:-30 to 70°C (-22 to 158°F) |
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity |
5 to 95% (30°C, non-condensing) |
| • Power Requirements |
| Connector |
4-pin removable terminal block |
| Input Voltage |
12 to 48 VDC, redundant dual inputs |
| Power Consumption |
9.6W (12V/0.7A to 48V/0.2A) |
| Reverse Polarity Protection |
Present |
| • Standards and Certifications |
| Safety |
OnCell G3470A-LTE-US: UL 60950-1 |
| EMC |
OnCell G3470A-LTE-US: FCC Part 15 Subpart B
OnCell G3470A-LTE-EU: EN 61000-6-2/-4 |
| Radio |
OnCell G3470A-LTE-US: FCC ID N7NMC7355
OnCell G3470A-LTE-EU: EN 301 489-1, EN 301 489-7, EN 301 511/4 |
| • Reliability |
| MTBF (mean time between failures) |
327,326 hrs |
