| Interface |
| RJ45 ports |
1 for Ethernet in, 1 for PoE out |
| LED Indicators |
Power, Power Device is detected |
| Power Input |
| Input Voltage for tNS-200IN |
+46 ~ +53 VDC |
| Input Voltage for tNS-200IN-24V |
+18 ~ +32 VDC |
| Power consumption for tNS-200IN |
0.4 A@ 48 VDC with PD full loading |
| Power consumption for tNS-200IN-24V |
0.9 A@ 24 VDC with PD full loading |
| Protection |
Power reverse polarity protection |
| Frame Ground for EMS Protection |
Yes |
| Connection |
4-Pin Removable Terminal Block |
| PoE Technology |
| PoE Compliance |
100% IEEE 802.3af compliant |
| PoE Classification |
PSE (Power Sourcing Equipment) |
| PoE Voltage |
+46 ~ +48 VDC depending on power input |
| PoE Power |
Up to 15.4 watts |
| PoE Operation |
Automatic detection and power management |
| PoE Pin assignments |
V+ (Pin 4,5), V- (Pin 7,8) |
| PoE disconnect mode |
DC disconnect |
| Mechanical |
| Casing |
Plastic |
| Flammability |
UL 94V-0 |
| Dimensions |
52 mm x 86 mm x 27 mm (W x L x H) |
| Installation |
DIN-Rail |
| Environmental |
| Operating Temperature |
-40 ~ +75 °C |
| Storage Temperature |
-40 ~ +85 °C |
| Ambient Relative Humidity |
10% ~ 90% RH, non-condensing |
