DA-IRIG-B-S-02-T - IRIG-B Expansion Module, PCI Interface, 1 Fiber IRIG-B in, 1 DB9M In/Out, 1 DB9M Out
by MOXA
|
|
|
|
- IRIG-B expansion module, PCI interface, 1 fiber IRIG-B in, 1 DB9M in/out, 1 DB9M
out
|
|
|
The DA-PHR-PTP expansion module is compliant with IEC 62439-3 Clause 4 (PRP)
and IEC 62439-3 Clause 5 (HSR) to ensure the highest system availability and
data integrity for mission-critical applications that require redundancy and
zero-time recovery.
With dual Gigabit Ethernet port design, the DA-PRP-HSR provides high
performance for redundant network systems. In addition, the DA-PRPHSR features a
built-in native PRP/HSR management middleware with MMS server that allows SCADA
to collect IEC62439-3 registers from multiple devices for easy network
diagnosis, troubleshooting, device management, and monitoring.
Moxa’s DA-820 series industrial computer with the DA-PRP/HSR is the ideal
solution for power substation automation and process automation systems.
|
• Ethernet
Interface |
|
LAN |
2 auto-sensing 100/1000 Mbps unmanaged Ethernet switch ports (RJ45) |
|
Magnetic Isolation Protection |
15 kV built-in |
|
• Physical
Characteristics |
|
Weight |
225 g |
|
Dimensions |
167 x 111 mm (6.6 x 4.38 in) |
|
• Environmental
Limits |
|
Operating Temperature |
-40 to 60°C (-40 to 140°F) |
|
• Standards
and Certifications |
|
Safety |
LVD, UL, cUL |
|
Electrical Substation |
IEC 61850-3, IEC 60255, IEEE 1613 |
|
Protection Relay |
IEC 60255 |
|
EMC |
FCC, CE (Class A) |
|
Green Product |
RoHS, CRoHS, WEEE |
|
• Warranty |
|
Warranty Period |
3 years |
|
Details |
See www.moxa.com/warranty |
|
• |
|
• Software
Specifications |
|
• PRP/HSR
Configuration Utility |
|
PRP/HSR mode selection |
|
|
Multiple PRP/HSR expansion card configuration |
|
• Built-in
MMS Server Management Middleware |
|
PRP/HSR device information collection using SNMP |
|
Transmission of IEC62439-3 registry information to SCADA |
|
|
