LP-8381 - Linux Controller with SVGA port, USB, Ethernet, Memory card and 4 slots built in
by ICP DAS
|
|
|
|
Linux Controller with Dual 10/100 Base-TX Ethernet Ports and 3 I/O slots and Linux Operating System. Supports operating temperatures between -25 ~ +75 °C (-13F ~ 167F).
|
|
|
Features
The LP-51xx series is equipped with a PXA270 CPU (520 MHz) running a Linux kernel 2.6.19 operating system, multiple communication interfaces, such as VGA, USB, Ethernet, RS-232/485 and audio ports. Further more, it also contains an optional I/O expansion board to implement various I/O functions, such as DI, DO, A/D, D/A, Timer/Counter, UART, flash memory, or battery backup SRAM, etc.
Main advantage of the LP-51xx series is its high quality control system, including its stability, small core size, optional I/O expansion board, support for Web services (Web/FTP/Telnet/SSH server), and multiple development environments (LinPAC SDK for Linux and Windows environment using the GNU C language, GUI software), etc., all of which give users the best features of both traditional PLCs and Linux capable PCs, meaning that it is one of the most powerful and flexible embedded control systems available.
- PXA270, 520 MHz CPU
- Linux kernel 2.6.19 Inside
- Embedded Service: Web Server, FTP Server, Telnet Server, SSH Server
- 64 MB Flash, 128 MB SDRAM
- Built-in Ethernet, USB, RS-232, RS-485 Ports
- Built-in 800 × 600 VGA Port
- Built-in Audio with Microphone-In and Earphone-Out
- I/O Expansion Board Optional
- Operating Temperature: -25 ~ +75°C
| Models-OD |
LP-5131 |
LP-5131-OD |
LP-5141 |
LP-5141-OD |
| OS |
Linux kernel 2.6.19 |
| Embedded Service |
Web Server, FTP Server, Telnet Server, SSH Server |
| SDK Provided |
Standard LinPAC SDK for Windows and Linux by GNU C language |
| CPU Module |
| CPU |
PXA270, 520 MHz |
| SDRAM |
128 MB |
| NVRAM |
31 Byte ( Battery backup , data valid up to 10 years ) |
| Flash |
64 MB |
| EEPROM |
16 KBData Retention: 40 years; 1,000,000 erase/write cycles |
| Expansion Flash Memory |
microSD socket with one 2 GB microSD card (support up to 32 GB microSDHC card) |
| RTC (Real Time Clock) |
Provide seconds, minutes, hours, day of week/month, month and year |
| 64-bit Hardware Serial Number |
Yes |
| Dual Watchdog Timer |
Yes |
| LED indicator |
3 Dual-Colors LEDs (PWR, RUN, L1~L4；RUN, L1~L4 for user programmable) |
| Rotary Switch |
Yes (0~9) |
| VGA & Communication Ports |
| VGA |
Yes
800 × 600 |
Ethernet
|
RJ-45 x 1, 10/100 Base-TX
(Auto-negotiating, Auto MDI/MDI-X, LED indicators) |
RJ-45 x 2, 10/100 Base-TX
(Auto-negotiating, Auto MDI/MDI-X, LED indicators) |
| USB 1.1 (host) |
2 |
1 |
Audio Port
(Microphone-In and Earphone-Out) |
|
| COM1 |
RS-232 (RxD, TxD and GND); Non-isolated |
| COM2 |
RS-485 (D2+,D2-); 2500 VDC; isolated |
| COM3 |
RS-232 (RxD, TxD and GND); Non-isolated |
| I/O expansion |
| I/O expansion bus |
I/O expansion board optional |
| Mechanical |
| Dimensions(W x L x H) |
91 mm x 132 mm x 52 mm |
| Installation |
DIN-Rail |
| Environmental |
| Operating Temperature |
-25°C ~ +75°C (-13°F ~ +167°:F) |
| Storage Temperature |
-30°C ~ +85 °C (-22°F ~ +176°F) |
| Ambient Relative Humidity |
5 ~ 90% RH, non-condensing |
| Power |
| Input Range |
+10 ~ +30 VDC |
| Isolation |
1 kV |
| Consumption |
4.8 W (0.2 A @ 24 VDC) |
|
|
